Choose ThinkBook 16 if you need:
- Processor Model at Core Ultra 5 (vs Intel Core i5 8250U 1.6GHz)
- Installed Memory at 16 GB (vs 8 GB)
- Storage Capacity at 512 GB (vs 256 GB)
- Display Size at 16 inch (vs 14 inch)
laptopedia
Side-by-side specification comparison of two reference models
Compare ThinkBook 16 vs ThinkPad E480
A full side-by-side comparison of reference models ThinkBook 16 and ThinkPad E480 within the same category.
Specifications
Side-by-side specification comparison of two reference models
| Specification | ThinkBook 16 | ThinkPad E480 |
|---|---|---|
| Price | Not for sale | Not for sale |
| General | ||
| Brand | Lenovo | Lenovo |
| Product Family | ThinkBook | ThinkPad |
| Model | ThinkBook 16 | ThinkPad E480 |
| Model Number | ThinkBook 16 G7 IML | ThinkPad E480 |
| Launch Year | 2025 year | 2018 year |
| Form Factor | Clamshell | Clamshell |
| Laptop Category | Business | Mainstream |
| Color | Arctic Grey | — |
| Operating System | — | Windows 10 |
| Operating System Architecture | 64-bit | 64-bit |
| Processor | ||
| Processor Manufacturer | Intel | Intel |
| Processor Family | Intel Core Ultra 5 | Intel Core i5 |
| Processor Model | Core Ultra 5 | Intel Core i5 8250U 1.6GHz |
| Processor Generation | Intel Core Ultra Series 1 | 8th Gen |
| CPU Architecture | x86-64 | x86-64 |
| CPU Process Node | — | 14 nm |
| CPU Cores | — | 4 cores |
| Efficiency Cores | — | 0 cores |
| CPU Threads | — | 8 threads |
| CPU Base Clock | — | 1.6 GHz |
| CPU Max Boost Clock | — | 3.4 GHz |
| L3 Cache | — | 6 MB |
| Processor Base Power | — | 15 W |
| AI / NPU | ||
| NPU | Yes | — |
| NPU Model | Intel AI Boost | — |
| NPU Performance | 11 TOPS | — |
| Graphics | ||
| Graphics Type | Integrated | Discrete |
| GPU Manufacturer | Intel | AMD |
| GPU Model | — | AMD Radeon RX 550 |
| VRAM Capacity | 0 GB | 2 GB |
| VRAM Type | Shared system memory | GDDR5 |
| Maximum External Displays | 3 displays | 1 displays |
| Maximum External Resolution | 5120 x 2880 @ 60Hz | 1920 x 1080 @ 60 Hz via HDMI |
| Memory | ||
| Installed Memory | 16 GB | 8 GB |
| Maximum Memory | 64 GB | 32 GB |
| Memory Type | DDR5 | DDR4 |
| Memory Speed | 5600 MT/s | 2400 MT/s |
| Memory Form Factor | SO-DIMM | SO-DIMM |
| Memory Slots | 2 slots | 2 slots |
| Memory Upgradeable | Yes | Yes |
| Memory Channels | Dual-channel | Dual |
| Storage | ||
| Primary Storage Type | SSD | SSD |
| Storage Capacity | 512 GB | 256 GB |
| Storage Interface | PCIe NVMe | PCIe NVMe |
| Storage PCIe Generation | PCIe 4.0 | PCIe 3.0 |
| Storage Form Factor | M.2 2242 | M.2 2280 + 2.5-inch |
| Installed Storage Drives | 1 drives | 1 drives |
| Maximum Storage Drives | 2 drives | 2 drives |
| M.2 Storage Slots | 2 slots | 1 slots |
| 2.5-inch Drive Bay | — | Yes |
| RAID Support | — | — |
| Card Reader | — | Yes |
| Card Reader Formats | SD | microSD |
| Display | ||
| Display Size | 16 inch | 14 inch |
| Display Resolution | — | 1920 x 1080 |
| Resolution Class | — | FHD |
| Display Technology | IPS LCD | IPS LCD |
| Panel Type | IPS | IPS |
| Display Brightness | — | 250 nits |
| Contrast Ratio | — | 400:1 |
| Aspect Ratio | 16:10 | 16:9 |
| Display Finish | Anti-glare | Anti-glare |
| Adaptive Sync Technology | — | — |
| Screen-to-Body Ratio | 90 % | — |
| Camera & Biometrics | ||
| Webcam Resolution | — | 720p |
| Camera Privacy Shutter | Yes | — |
| Audio | ||
| Speaker Configuration | Stereo speakers, 2W x2 | 2 x speakers |
| Speaker Power | 2 W x 2 W | 2 x 1.5 W |
| Audio Technology | Dolby Audio | Dolby Advanced Audio |
| Microphone Configuration | Dual-microphone array with smart noise-cancelling | Dual-array microphone |
| Audio Jack | Yes | Yes |
| Keyboard & Input | ||
| Keyboard Type | 6-row keyboard | Spill-resistant 6-row keyboard |
| Keyboard RGB Zones | — | — |
| Numeric Keypad | Yes | — |
| Spill-Resistant Keyboard | Yes | — |
| Key Travel | 1.5 mm | — |
| Copilot Key | Yes | — |
| Touchpad Type | Precision TouchPad | ThinkPad Mylar touchpad |
| Touchpad Dimensions | 120 x 75 mm | — |
| Touchpad Material | Mylar | Mylar |
| Pointing Stick | — | Yes |
| Wireless & Networking | ||
| Wi-Fi Standard | — | Wi-Fi 5 |
| Wi-Fi IEEE Standard | — | 802.11ac |
| Wi-Fi Bands | — | Dual-band |
| Bluetooth Version | — | 4.1 |
| Ethernet | Yes | Yes |
| Ethernet Speed | 1 | 1 GbE |
| WWAN | No | No |
| SIM Slot | — | — |
| Ports & Expansion | ||
| USB Type-A Port Count | 2 ports | 3 ports |
| USB Type-A Specifications | USB 5 Gbps (USB 3.2 Gen 1) | 2x USB 3.1 Gen 1; 1x USB 2.0 |
| USB Type-C Port Count | 2 ports | 1 ports |
| USB Type-C Specifications | USB 10 Gbps + Thunderbolt 4 / USB4 40 Gbps; USB PD; DisplayPort | 1x USB-C 3.1 Gen 2 / Power Delivery / DisplayPort |
| USB4 Port Count | 1 ports | 0 ports |
| USB4 Speed | 40 Gbps | — |
| Thunderbolt Port Count | 1 ports | 0 ports |
| Thunderbolt Version | Thunderbolt 4 | — |
| HDMI Port Count | 1 ports | 1 ports |
| HDMI Version | 2.1 | 1.4b |
| DisplayPort Output | Yes | DisplayPort via USB-C |
| RJ-45 Port Count | 1 ports | 1 ports |
| 3.5 mm Audio Combo Port Count | 1 ports | 1 ports |
| SD Card Slot Count | 1 ports | 0 ports |
| microSD Card Slot Count | 0 ports | 1 ports |
| Smart Card Reader | No | No |
| Security Lock Slot | — | Yes |
| Internal PCIe Slots | 2 x M.2 PCIe 4.0 x4 storage slots | 1x M.2 storage slot |
| Battery & Power | ||
| Battery Capacity | — | 45 Wh |
| Battery Chemistry | — | Li-polymer |
| Battery Life | — | 13.51 hours |
| Battery Life Test Method | — | MobileMark 2014 |
| Fast Charging | — | Yes |
| Fast Charge Level | — | 80 % |
| Fast Charge Time | — | 60 min |
| Power Adapter | — | 65 W |
| Power Connector | — | USB-C |
| USB-C Charging | — | Yes |
| USB Power Delivery Version | USB Power Delivery 3.0 | — |
| Dimensions & Build | ||
| Width | 356 mm | 329 mm |
| Depth | 253.5 mm | 242 mm |
| Thickness | 17.5 mm | 21.9 mm |
| Weight | 1.7 kg | 1.75 kg |
| Chassis Material | Aluminium top, PC-ABS bottom | PC/ABS |
| Lid Material | Aluminium | PC/ABS |
| Base Material | PC-ABS | PC/ABS |
| MIL-STD Testing | MIL-STD-810H | MIL-STD-810G tested |
| Security & Manageability | ||
| TPM | Firmware TPM 2.0 | — |
| BIOS / UEFI Password Support | Yes | Yes |
| Drive Password Support | Yes | Yes |
| Enterprise Manageability | — | — |
| Smart Card Support | No | No |
| BIOS Recovery / Self-Healing | Yes | — |
| Certifications & Sustainability | ||
| ENERGY STAR | — | ENERGY STAR 8.0 |
| EPEAT | — | Gold |
| TCO Certified | TCO Certified 9.0 | TCO Certified |
| RoHS Compliance | Yes | Yes |
| Recycled Materials | 25% PCC battery enclosure; 50% PCC keycaps; 30% PCC speaker enclosure; 90% PCC 65W adapter | — |
| Environment & Warranty | ||
| Operating Temperature | 5–35 °C | — |
| Operating Humidity | 8–95 % RH | — |
| Storage Temperature | 5–43 °C | — |
| Warranty | — | 1 years |
| Warranty Type | — | Mail-in or depot limited warranty |
Summary: Which Product Should You Choose?
Choose ThinkPad E480 if you need:
- Processor Model at Intel Core i5 8250U 1.6GHz (vs Core Ultra 5)
- Installed Memory at 8 GB (vs 16 GB)
- Storage Capacity at 256 GB (vs 512 GB)
- Display Size at 14 inch (vs 16 inch)
What is the difference between ThinkBook 16 and ThinkPad E480?
ThinkBook 16 and ThinkPad E480 share specifications such as Brand (Lenovo), Form Factor (Clamshell), Operating System Architecture (64-bit), Processor Manufacturer (Intel).
The main differences: Processor Model (ThinkBook 16: Core Ultra 5, ThinkPad E480: Intel Core i5 8250U 1.6GHz); Installed Memory (ThinkBook 16: 16 GB, ThinkPad E480: 8 GB); Storage Capacity (ThinkBook 16: 512 GB, ThinkPad E480: 256 GB); Display Size (ThinkBook 16: 16 inch, ThinkPad E480: 14 inch).
ThinkBook 16 may suit users who need its differing values, while ThinkPad E480 benefits those who need its paired strengths. Review the specs table above before deciding.
